Product Feature
1. Direct acting type and normally closed mode, flexible in direction change.
2. No need to add oil for lubrication.
3. Several valves can be installed integratedly to save installation space.
4. Affiliated manual devices are equipped to facilitate installation and debugging.
5. Several standard voltage grades are optional.
Electromagnetic valve overall profile manufacturing, the use of slot structure to high-precision processing technology to protect product performance, the product is compact, rational design, good commutation, and can be integrated on the floor, occupies a small space, easy maintenance.
With solenoid operated for control appropriate flow and direction, provide great performance.
Alloy body have a long lifespan, perfect for electrically driven pneumatic power control.
2 position 5 way with 2 inlet, 1 oulet and 2 exaust.
2 position 3 way with 1 inlet, 1 oulet and 1 exaust.
| Model | 3YV1-M5 | 3YV1-06 |
| Working Medium | 40 Micron Filtered Air | |
| Motion Pattern | Direct Drive Type | |
| Joint Pipe Bore | M5 | 1/8″ |
| Aperture of flow Rate | 1.0mm | |
| Working-Pressure | 0～0.8MPa | |
| Max Pressure Resistance | 1.2MPa | |
| Operating Temperature | –5～80℃ | |
| Voltage Range | ±10% | |
| Power Consumption | AC: 5.5VA DC: 4.8W | |
| Insulation& Protection Class | F Class.IP65 | |
| Wiring Form | Lead Wire or Connector type | |
| Shortest Excitation Time | 0.05Second | |
PT thread, NPT thread and G thread are available.
Coil Specification
| Item | Specification |
| Standard voltage | AC220V,AC110V,AC24V,DC24V,DC12V |
| Scope of voltage | AC+-15%,DC+-10% |
| Power consumption | AC:3.5VA; DC:3.0W |
| Protection | IP65 |
| Temperature classification | B class |
| Electrical entry | Terminal, Grommet |
| Activating time | 0.05sec and below |
| Max.frequency | 10 cycle/sec |
